Our services at a glance

Find the information you need quickly and easily. If you require further information on delivery dates, logistics and shipment, prices and payment terms, please contact our sales department directly.

Process	Parameter	Surface	min.	max.
Rolling	Ø Length Tolerance Straightness Treatment condition Other	black	12,00 mm 5.760 mm DIN EN 10060 (P) 4 mm/m As rolled (+AR), Controlled rolling (+CR), Hardened (+H) Minimum quantity 3 tons, however < 10 tons only upon request	40,00 mm 18.000 mm
Heat-treatment	Ø Length Treatment Other		12,00 mm 3.000 mm +S (C) +A (G) +AC (GKZ) +N +FP (BG) +TH (BF) +SR (S) Cooling: Still and moving air Special structures upon request Coils piece goods upon request	200,00 mm 18.000 mm
Straigthening	Ø Length Straightness	black	12,00 mm < Ø 20 mm: 3.000 mm Ø 20 mm: 3.000 mm 2 mm/m	42,00 mm < Ø 20 mm: 8.000 mm
Blasting	Ø Length		12,00 mm 4.000 mm	75,00 mm 18.000 mm
Sawing	Ø Bar length Delivery length Tolerance Other	black bright black bright black bright black bright	12,00 mm 11,00 mm 3.000 mm 3.000 mm 2.940 mm 150 mm + / - 15 mm + / - 0,5 mm Bar ends burr-free	100,00 mm 41,50 mm 15.000 mm 8.450 mm 14.940 mm 6.480 mm
Peeling	Ø Length Tolerance Roundness Straightness Roughness	black bright	12,00 mm 11,00 mm 3.000 mm Up to h9 (DIN EN 10278) Others upon request According to Ø and DIN EN 10278 2 mm/m Rz <= 20μm; Ra <= 3 μm	46,00 mm 45,00 mm 8.400 mm
Polishing	Ø Length Roundness Straightness Roughness	bright	11,00 mm 3.000 mm According to Ø and DIN EN 10278 1 mm/m Rz <= 10 μm; Ra <= 1 μm	40,00 mm 8.400 mm
Grinding	Ø Length Tolerance Roundness Straightness Roughness	bright	11,00 mm 1.800 mm Up to h6 (DIN EN 10278) According to Ø and DIN EN 10278 0,5 mm/m Rz <= 10 μm; Ra <= 1 μm	45,00 mm 8.100 mm
Chamfering	Ø Length Chamfer angle Chamfer width	black bright black brigth	12,00 mm 12,50 mm 3.000 mm 150 mm 30° / 45° / 60° max. 6 mm at 30° max. 10 mm at 45°	40,00 mm 41,50 mm 8.000 mm 3.470 mm
Deburring	Ø Length Removal	bright	12,50 mm 150 mm max. 2 mm	41,50 mm 3.470 mm
Machining	Ø Length Spectrum		12,50 mm 150 mm Centering hole axial; radial grooves	41,50 mm 3.470 mm
Crack testing	Ø Length		11,00 mm 3.000 mm	40,00 mm 8.400 mm
Eddy current test method Flux leakage method	Reference crack depth	black bright	DIN EN 10221 max. 0,20 mm DIN EN 10277-1 max. 0,15 mm
Internal defect testing	Ø Length Reference defect	blasted bright	11,00 mm 3.000 mm DIN EN 10308 max. KSR 1,0 mm DIN EN 10308 max. KSR 0,7 mm	40,00 mm 8.400 mm
Identification testing	Ø Length		11,00 mm 3.000 mm	40,00 mm 8.400 mm
Packing / Labelling	Bundles Labels Protection Other		Steel strip, wire VDA, barcode or standard Bar ends with paint marking and/or adhesive labels Steel strip and crepe tape Spacer rings LuPo-foil Anti-corrosive oil Lamiflex packing Oil paper Wooden or steel crate (max. 800 - 1.300 kg) Bundle weight max. 5 tons
